Product
Pump Model	DES200-170-315/2
Pump Type

Pump Performance
Rated Flow	450m3/h
Rated Head	170m
Rated Speed	2980r/min
Eff.	%

Shaft Seal
TYPE
SIZE	m
MATERIAL	CAR/SIC/VITON

Liquid
Liquid Transport	Water
Liquid Temperature Range	-15-120℃
Liquid Temperature	20℃
Density	998.2kg/m3
Viscosity	mm2/s
Solid Content	%
Solid Size	mm

Material
Pump body	HT250/304
Casing	HT250/304
Impeller	HT250/304
Shaft	45
BASE	Q235-A

Other
Net Weight	3163kg
Gross Weight	kg
Transport Volume	m3
PUMP	kg
BASE PLATE	kg

Installation
Maximum ambient temperature	60℃
Maximum operating pressure	bar
Flange standard	GB
Pump Inlet	DN200
Pump Outlet	DN150
Pressure Level
COUPLING
COUPLING COVER
IMPELLER
ROTATION VIEWED FROM DRIVER
Driven
End

Motor
MFG.
Motor Model	355(6KV)
ENCLOSURE
R.OUTPUT
Rated Power	315KW
Motor Pole	2
Rated Speed	2980r/min
Frequency	50HZ
Efficiency
Insulation Class	F
Rated Voltage	φ3x6KV
Rated Electric
Motor Efficiency Level	IE3、IE4
Protection Level	IP55
Driven
End

ACCESSORIES
COUPL.SET
BASE PLATE
COUNT.FLANGE
PRESS.GUAGE
FUNNEL
SUC.STRAINER
