	Product Model	Rated Flow (m³/h)	Flow Range (m³/h)	Rated HeadH (m)	Head Range (m)	Motor Power (kW)	Frequency(HZ)
Performance Curve	XRL1-1/DRL1-1（X）3000rpm	1.8	0-2.4	5.2	7-3.7	0.37	50
Performance Curve	XRL1-2/DRL1-2（X）3000rpm	1.8	0-2.4	10.4	12-7.5	0.37	50
Performance Curve	XRL1-3/DRL1-3（X）3000rpm	1.8	0-2.4	16	18.8-10.8	0.37	50
Performance Curve	XRL1-4/DRL1-4（X）3000rpm	1.8	0-2.4	20	24-14	0.37	50
Performance Curve	XRL1-5/DRL1-5（X）3000rpm	1.8	0-2.4	24	30.5-16	0.37	50
Performance Curve	XRL1-6/DRL1-6（X）3000rpm	1.8	0-2.4	29	36-19	0.37	50
Performance Curve	XRL1-7/DRL1-7（X）3000rpm	1.8	0-2.4	33	43-22	0.37	50
Performance Curve	XRL1-8/DRL1-8（X）3000rpm	1.8	0-2.4	38	49-25	0.55	50
Performance Curve	XRL1-9/DRL1-9（X）3000rpm	1.8	0-2.4	42	55-26	0.55	50
Performance Curve	XRL1-10/DRL1-10（X）3000rpm	1.8	0-2.4	47	61-30	0.55	50
