	Product Model	Rated Flow (m³/h)	Flow Range (m³/h)	Rated HeadH (m)	Head Range (m)	Motor Power (kW)	Frequency(HZ)
Performance Curve	XRL3-1/DRL3-1（X）3000rpm	3	0-4.5	4.8	7-2	0.37	50
Performance Curve	XRL3-2/DRL3-2（X）3000rpm	3	0-4.5	9.6	14-4	0.37	50
Performance Curve	XRL3-3/DRL3-3（X）3000rpm	3	0-4.5	15	20-10	0.37	50
Performance Curve	XRL3-4/DRL3-4（X）3000rpm	3	0-4.5	19	26-10	0.37	50
Performance Curve	XRL3-5/DRL3-5（X）3000rpm	3	0-4.5	23	33-12	0.37	50
Performance Curve	XRL3-6/DRL3-6（X）3000rpm	3	0-4.5	28	40-15	0.55	50
Performance Curve	XRL3-7/DRL3-7（X）3000rpm	3	0-4.5	32	45-16	0.55	50
Performance Curve	XRL3-8/DRL3-8（X）3000rpm	3	0-4.5	38	53-19	0.75	50
Performance Curve	XRL3-9/DRL3-9（X）3000rpm	3	0-4.5	42	60-21	0.75	50
Performance Curve	XRL3-10/DRL3-10（X）3000rpm	3	0-4.5	47	66-23	0.75	50
