Application:Water supply system,boiler water feed system,fire fighting system,washing system, Hot and cold water circulation system, Fire sprinkling system
| Product Model | Rated Flow (m3/h) | Flow Range (m3/h) | Rated HeadH (m) | Head Range (m) | Motor Power (kW) | Frequency(HZ) | ||
|---|---|---|---|---|---|---|---|---|
| Performance Curve | XRL4-1/DRL4-1（X） | 5 | 0-8 | 7.5 | 10-3 | 0.37 | 50 | |
| Performance Curve | XRL4-2/DRL4-2（X） | 5 | 0-8 | 15 | 21-4 | 0.37 | 50 | |
| Performance Curve | XRL4-3/DRL4-3（X） | 5 | 0-8 | 22 | 31-10 | 0.55 | 50 | |
| Performance Curve | XRL4-4/DRL4-4（X） | 5 | 0-8 | 30 | 39-12 | 0.75 | 50 | |
| Performance Curve | XRL4-5/DRL4-5（X） | 5 | 0-8 | 37 | 50-18 | 1.1 | 50 | |
| Performance Curve | XRL4-6/DRL4-6（X） | 5 | 0-8 | 44 | 60-20 | 1.1 | 50 | |
| Performance Curve | XRL4-7/DRL4-7（X） | 5 | 0-8 | 52 | 71-22 | 1.5 | 50 | |
| Performance Curve | XRL4-8/DRL4-8（X） | 5 | 0-8 | 59 | 80-30 | 1.5 | 50 | |
| Performance Curve | XRL4-9/DRL4-9（X） | 5 | 0-8 | 66 | 90-34 | 2.2 | 50 | |
| Performance Curve | XRL4-10/DRL4-10（X） | 5 | 0-8 | 74 | 101-38 | 2.2 | 50 |
