Application:Water supply system,boiler water feed system,fire fighting system,washing system, Hot and cold water circulation system, Fire sprinkling system
| Product Model | Rated Flow (m3/h) | Flow Range (m3/h) | Rated HeadH (m) | Head Range (m) | Motor Power (kW) | Frequency(HZ) | ||
|---|---|---|---|---|---|---|---|---|
| Performance Curve | XRL10-1/DRL10-1（X） | 10.5 | 0-13 | 6.5 | 10-4.5 | 0.75 | 50 | |
| Performance Curve | XRL10-2/DRL10-2（X） | 10.5 | 0-13 | 14 | 20-10 | 0.75 | 50 | |
| Performance Curve | XRL10-3/DRL10-3（X） | 10.5 | 0-13 | 21.5 | 31-16 | 1.1 | 50 | |
| Performance Curve | XRL10-4/DRL10-4（X） | 10.5 | 0-13 | 30 | 41-22 | 1.5 | 50 | |
| Performance Curve | XRL10-5/DRL10-5（X） | 10.5 | 0-13 | 38.5 | 51-28 | 2.2 | 50 | |
| Performance Curve | XRL10-6/DRL10-6（X） | 10.5 | 0-13 | 45.5 | 61-33 | 2.2 | 50 | |
| Performance Curve | XRL10-7/DRL10-7（X） | 10.5 | 0-13 | 54 | 72-40 | 3 | 50 | |
| Performance Curve | XRL10-8/DRL10-8（X） | 10.5 | 0-13 | 61.5 | 82-45 | 3 | 50 | |
| Performance Curve | XRL10-9/DRL10-9（X） | 10.5 | 0-13 | 68.5 | 92-51 | 3 | 50 | |
| Performance Curve | XRL10-10/DRL10-10（X） | 10.5 | 0-13 | 77.5 | 102-58 | 4 | 50 |
